The Alpha SS34+ is a rust-resistant, 17-section stainless steel whip that extends to 34.5 feet and collapses to approximately 29 inches. Its premium stainless steel telescopic sections make it an ideal choice for building collapsible multi-band portable antennas.
WARNINGS
Electrical precautions should always be taken when deploying antennas
The SS34+ should only be used with a sturdy mounting solution
The SS34+ should not be used with the Alpha Antenna Auto Match nor the HexTenna Hub
It is necessary to Guy this system with your ropes and anchors to the included Guying Adapter when deployed for 30/40 meters or it will bend and sway. Guying may also be required on other bands if wind conditions require it.
Features:
Usage: Perfect for EmComm, POTA, SOTA, DXpeditions, and other portable deployments.
Compatibility: Equipped with a 3/8-24 mounting stud for easy integration with the Alpha Antenna ‘Top of Mast Mount’.
Durability: Laser engraved with Alpha Antenna on the base adapter, which is milled and fitted to the telescopic elements (not crimped) for ruggedness and stability.
Options may be purchased by clicking each of the following:
4 x 35′ Radial Kit by Alpha Antenna
SS34+ Guying Kit by Alpha Antenna
Zippered non-padded gear bag with carrying strap by Alpha Antenna
Deployment:
Deployment: Deploy by extending or retracting the telescopic whip for resonance for use as an omni-directional vertical on 40 through 2 meters when radials are installed on the ground side of a sturdy mounting solution.
Stability: Always guy this system when deployed for 30 or 40 meters.
- You will need to supply your own guying anchors.Â
Specifications:
PEP Rating: 1000W
Materials: Stainless Steel
Band Coverage: 2M to 40M with optional radials
Dimensions:
Base Diameter: ~ 1.00″
Largest Element Diameter: ~ 0.90″
Length (Collapsed): ~ 29″
Length (Extended): ~ 34.5′
Weight: ~ 2.3 lb.
Non-Guyed Deployment in 15MPH Wind Gust
* Guying is required when fully deployed
