10-40 Meter 100W Base Alpha Magnetic Loop + Remote
$999.00
Remotely controlled 10-40 meter magnetic Alpha Loop for indoor or permanent outdoor base deployments.
Description
The 10-40 Meter 100W Base Alpha Magnetic Loop + Remote. Base and transportable Alpha Loop for permanent or temporary indoor or outdoor deployments with coverage of 10-40 Meters rated at 100 PEP SSB, 50 CW, or 25 watts for sporadic digital modes (10 watts for continuous digital modes).
Summary:
This is a 3 foot wide permanent outdoor or indoor antenna that can be easily deployed for base deployments or transported for easy remote deployments. The 40 to 10 meter (transmitting and receiving) Alpha Loop is a complete circuit, so there is no need for radials or counterpoise. It also includes a remotely controlled tuner that is manually tuned with a wired remote control.
Included:
Matching network
Remote Control and power supply
Inner Loop with SO239 for connecting the system to your equipment
Outer Loop
Mounting hardware that enables the system to be installed on a mast up to 1 1/4″ in diameter
Hints & Kinks
Minimum mounting height is 1 loop diameter high (about 3 feet or higher).
The Alpha Loop can be placed higher so it sees above and past obstacles.
Attic installations with asphalt shingles typically see a little more than 1 S-Unit of loss.
Can be mounted horizontally on your mast to enhance Omnidirectional and NVIS performance.
Total maximum tuning time from 7.0MHz to 29.7MHz is 90 seconds with the tuning speed knob is turned completely to the right for maximum tuning speed.
Tapping the left or right button allows for easy step tuning.
NOTE – When mounted vertically, the Alpha Loop has radiation patterns that begin to overlap in the far field, minimizing directionality. While at the same time remaining fairly directional in the near field, which increases its’ ability to null out noisy electronics that cause interference.
Watch The Setup Video ~ CLICK HERE~
CUSTOMER PHOTOS
![]()
Alpha Base Loop after the storm – N0CWQ
Alpha Base Loop before the storm – N0CWQ
Read more about the storm CLICK HERE
Base Loop – N0ML
We are dedicated to improving our antennas. Specifications and descriptions are subject to change without notice.
If you have a suggestion on price or how to improve this product, please send us your feedback by CLICKING HERE.
Additional information
| Weight | 144 oz |
|---|---|
| Dimensions | 19 × 19 × 5 in |
| condition | New |
| availability | in stock |
| mpn | BaseLoop |
| product type | Base Antennas, EmComm Antenna, HF Antenna, Magnetic Loop MagLoop Antenna, Marine Mobile Antenna, Military Aviation Commercial Antenna, Portable Antenna |
| Manufacturer | Alpha Antenna |
| color | Black |
| brand | Alpha Antenna |
